Swift // NG our performance wing foil board

Move your wing foiling to the next level
on a Swift // NG wing foil board...

SWIFT // NG

Board shown NG 90L with custom SurfDek and split grey/white colour

The SWIFT // NG is our performance wing foil board for experienced riders looking to progress. It is available in 6 standard sizes which can be customised to suit you.

Light weight and strong

Our carbon Innegra / epoxy construction for our wing foil boards is bullet proof but remains light weight. This provides the best combination between performance and durability.

Evolving shape

While sticking with the key features which identify the NG wing foil board we are constantly developing the design making incremental improvements to stay ahead of the curve.

Quick release design

The NG wing foil board is designed to get up and go. Easy to pump and quick to break from the water to give you the best ride.

3D view

SWIFT // NG

Board shown is NG 75L
NG 60L wing foil board
NG 60L wing foil board

The details

SWIFT // NG wing foil board is built to order in 6 proven sizes.

Unlike the mass-producers, we cut each board individually and will customise details and dimensions to suit you.

NG 50L

50 litres
4' 8"
23"
1245.00

NG 60L

60 litres
4' 10"
23"
1295.00

NG 70L

70 litres
5'
24"
1295.00

NG 75L

75 litres
5'
24"
1345.00
> BEST SELLER

NG 80L

80 litres
5'
25"
1345.00

NG 90L

90 litres
5' 2"
26"
1395.00
> NEW 2023

Built with ultra durable carbon innegra & epoxy

The SWIFT // NG wing foil board is built with a premium Carbon Innegra cloth and epoxy resin as standard. We use a vacuum epoxy construction to maximize the fiber to resin ratio. This creates a stronger tougher laminate giving it the ability to take those inevitable knocks.

75L NG wing foil board
NG 75L wing foil board in standard blue white split colour

Finished in a super hard polished epoxy in blue / white.

Unlike the big brands, we do not use fillers and paint which can easily chip and scratch. We pigment the epoxy with your chosen colour and finish with a clear epoxy gloss coat. This creates the most durable finish possible.

or customise with your own colour scheme

Choose from a range of single, dual colour and fully custom multi colour styles.

With a choice of epoxy pigments and styles we will make your board unique

We fit indestructible foil boxes

We have one of the strongest foil boxes on the market. Carbon reinforcement and high density foam inserts tie the top and bottom laminates of the board together, sharing the load between them. This provides you the rider with that ultra rigid and connected feel.

Tell us your foil brand and we will customise the foil box location to suit you. We fit both 10.75″ and 16″ tracks as well as a full carbon deep Tuttle (for the racers out there).

75L NG wing foil board foot strap options

and give you a range of footstrap options

wing foil board foot strap set up
Footstraps or not? We can build you this board without footstrap inserts or with one of 4 pre-set  insert layouts to suit your preferred stance. And, if we haven’t already got the layout for you, then customise it your way to get it exactly the way you like

Supagrip deckpad as standard or go custom with Surfdek

wing foil board supagrip
3M Supagrip deckpad

Customers reviews

Absolutely love my custom Swift NG 85. So much more slippery and easy to get foiling than on the 95 litre big-brand board I was on before. Lighter, much stronger, better looking with an excellent finish and not as expensive - it's a no-brainer!
80L NG wing foil board heading out for a ride
Will Becker
West Wittering

Tech details

All our boards are built using an epoxy vacuum construction. Epoxies have superior strength compared to cheaper alternative polyester resins so it was an easy decision for us to make.

Vacuum bagging boards during lamination applies an even pressure over the surface which allows us to achieve a greater fibre density within the resin matrix, resulting in a stronger, lighter board.

Our wing foil boards are laminated with a hybrid cloth woven from both Carbon and Innegra fibres.

Carbon fibre has an excellent strength to weight ratio having a low density, high tensile strength and a high Young’s Modulus (stiffness).  However, it fails catastrophically due to poor fracture toughness. For this reason full carbon boards are easily damaged and tend to be over built to compensate for this, actually making them heavier.

Innegra is a strong, light weight fibre. Having similar properties to kevlar it is incredibly tough. However, unlike kevlar which wicks water, Innegra is hydrophobic, making it the perfect material for water sports equipment.

By combining Carbon and Innegra in one weave, we get the benefits of both. We have run multiple tests on different layups and chosen the layup with the best balance of strength and weight.

We pigment the epoxy during construction rather than painting our boards.  Unlike others, you can clearly see we are not using paint to cover up fillers!  This also helps keep the weight down and gives a more durable finish that wont scratch off when you put the wing foil board down on the beach.

Each board is sanded by hand.  This makes each board unique and one of a kind.

We then finish with a clear UV stabilised epoxy gloss coat polished to a shine.

All our wing foil boards are designed on specialist computer aided design software.  This defines the shape and allows us to understand the hydrodynamics including drag, centre of buoyancy and volume distribution. We can prototype new shapes quickly and adjust the design for the optimum board – we go from a concept to a test board within a week which gives us a fantastic feedback cycle to ensure we develop quickly.  Using CNC machining  we get great accuracy and repeatability of profiles that you could not get from hand shaping.

We believe we have created one of the strongest foil boxes on the market.

The foil Box is the most highly stressed point on the board and as such required us to design and engineer a solution to handle these loads.

We manufactured multiple inserts to transfer these high loads though the board and further strengthened this area with carbon.

We install lifting handles on the bottom to make getting to the water that bit easier.  It is fitted on the bottom so that the wing can be kept away from the foil when carrying everything to the water.

A ‘Gore’ self venting plug is fitted.  This prevents the building of pressure within the board, caused by changes in core temperature or altitude when flying.

Angus comments....

The trend towards high aspect foils has required a change in board design.

The speed at which foils become effective is drastically different when comparing low and high aspect foils.

HA foils will stall if you try to pop up onto the foil to early. Thus the design is focused around creating a board that planes early and has low drag.

We keep the NG under constant development.  This year we added a dropped concave deck.  This provides an assured feel under foot and improves rail to rail weight transfer resulting in a more responsive ride. Paired with a 2 or 3 strap set up with 5 hole adjustability allows you to tweak your stance.   In August 2023 we added a 90litre NG to extend the range – this has a slightly wider tail to provide the added buoyancy for larger riders.

Our “Built Better” Carbon Innegra layup gives a lightweight, ultra tough and durable board that wont ding every time it takes a knock.

Ringing a 80L NG wing foil board Antigua

Why buy Swift Foiling ?

QUALITY

With the big brands you are paying for cheap materials, freight from China, multiple reseller markups, and delivery miles. With SWIFT you are paying for quality materials - epoxy and carbon, producing solid builds that last. No markups - we sell direct to you.

RAPID INNOVATION

With the big brands it can take up to a year for product innovations to appear on a mainstream board. Swift products are continuously developed and every board is current

DEAL WITH THE DESIGNERS

When you buy direct, you deal with the people that design and build your board. If the wind is up, we are riding and testing every week of the year. We know what works.

See what others on the beach are saying...

Build your wing foil board online and order today...

NG order form

Please enable JavaScript in your browser to complete this form.
1Swift // NG board builder - make it yours...
2Your details

Build and order your new wing foil board here

Choose from the options to setup your new SWIFT // NG wing foil board.

Our boards are built to order.  The time for a standard board is currently 3 weeks from cleared payment.

We enjoy customising boards and will work with you to make yours unique and the best board on the beach!     Customisation does add a little delay as we cannot start the build until we have confirmed any changes with you.





Model

Board size

Standard is 10 more litres than your bodyweight in kg. More experienced water-starters will go far smaller.

Construction

How would you like this board built?
The standard construction is Carbon Innegra this is a super durable construction. We can build this board in full carbon construction with full show layup. This looks fantastic and comes out lighter, but carbon is not as durable.

Colours and graphics

Select design
Board shown is NG 75L wing foil board for illustration
£0.00

Deck options

Footstrap inserts
Illustration foot strap layout is show on a NG 75L
Add Footstraps
Deckgrip
SurfDek is a premium deckgrip custom made to each board. There is a choice of 8 colours and any design

Bottom options

We fit foil boxes in black. These are super strong. If you advise us your foil brand we will locate box appropriately. Please note that the longer foil box adds weight and should not be specified if not needed.
Please advise your intended foil brand (if known) as it can help optimise track location.
Some riders don't require a handle on smaller boards.

Anything else ?

Please advise of anything else we should know
Click or drag files to this area to upload. You can upload up to 3 files.
Need to send us a layout sketch or a colour diagram, then do so here - thanks
If you have been given an order code by us, please add here
£0.00
